We have been lucky enough to get a few early examples of Blue’s new Triad SL Limited edition “super bikes”. These are no-compromise aero missiles with proprietary integrated front ends – super light, stiff and aero. Only 200 will be made in the murdered-out black-on-black limited edition garb. The first two guys we have riding these had the following comments after their first races on the Triad SL:

“Just wanted to give you guys a quick “THANK YOU” for getting me set up on the Blue. I have NEVER been more comfortable on a bike in my life. I was able to sit in the bars for 99% of the race. I have never been able to do that. Avg 24.5mph @ 260W.” – PW, QT2 Systems, 2:19 bike split at 70.3 Galveston.

“I’ve never been so comftorable and settled… The bike and the fit was perfect!!! 23.5mph @ 225 watts felt like I was flying….. Technical course and handled great…. I’ll bet a wide open course where I’m not so wimpy and this thing will be even more amazing!!!!” – DM, AG win Nautica Miami Beach

Great bike, but of course the fit helps too… Since this bike uses and integrated front end, you need to have your fit pretty dialed to select which stem length (stem is inetgrated into the bars) you need.

Check out our review:

Clearly Rinnie is one of the best triathletes the sport has ever seen. But versus the other top women she is giving up 5-20 minutes on the bike in Kona. If she could gain 10 minutes of free speed it would be devastating to the rest of the field. We think she can gain that much time via position adjustments and pedal stroke work. In the following video we analyze her pedal stroke and bike fit out on the Queen K. We Compare her to top riders Julie Dibens, Caroline Steffen, and Chris Lieto.

Here are the first of my annual high-speed cycling videos from Kona. The top male and female pros are shown at about mile 109 on the Queen K. Slo-mo portions are shot at 300 fps.

Goggles are a very small yet extremely important part of your Tri-arsenal. They can turn an otherwise great swim into a zig-zagging, eye burning debacle. I have been searching for goggle nirvana for 20 years, and maybe, just maybe I found it on the Kona pier this am. Tyr’s new “Special Ops” polarized goggle is by far the best I’ve tried. Lis and I swam out from DigMe Beach into the swell and chop this morning, and after a few hundred yards we both looked at each other and shouted in unison, “Best goggles ever!”.

The Special Ops goggles have unmatched visual clarity, and did an amazing job of cutting the 7am Kona glare. Sighting buoys was dramatically easier. Underwater clarity was great too. But it’s not just the lenses that rock – the fit and comfort does too. The gaskets are quite soft, and seal perfectly while not sucking your eyeballs out of your skull. Lis and I usually need different goggles, as she has a small face and I have a larger one with much bigger eye sockets. Amazingly, the Special Ops fit us both perfectly. Not one drop of leakage and no raccoon-eyes after the swim.

What’s the downside? You can’t get them til Spring 2012. At least that’s what we hear. They will retail for $30 – well worth it. But if you really want a pair now, you can try bribing me. It’ll take well into the 3 figures though.

Another great day at IM USA 2011, with fantastic efforts by all and excellent results for TTBikeFit athletes and Fuel Belt Race Team members. It got pretty hot on the run, but the wind on the bike course was apparently not as brutal as it had been in the days leading up to the race. I shot some high-speed video footage of the top pros on the bike and run. The first video looks at winner TJ Tollakson’s unconventional bike setup. For more on TJ’s 15 yr-old bike click HERE. The second looks at Women’s winner Heather Wurtele on her Blue Triad SL, and the third shows men’s 2nd and 1st finishers Ben Hoffman and TJ on run.

I am lucky to be able to work with a lot of fast athletes – the pointy end of the age groupers, and some pros. Of course it is gratifying to help them get even faster. What many folks don’t know is that I work with many other kinds of athletes too. And just because they aren’t necessarily looking for a Kona slot doesn’t mean it is any less gratifying to achieve good results.

Take Maryann G for example – she will be moving to the 70-74 age group this season, and has been racing about 15 years with the last 10 focused on long course. Unfortunately she has missed the bike cutoff in her last two Ironman attempts. Nothing to be ashamed off, especially when one of those races was Lake Placid (I know a thing or two about not finishing that course).

I had worked with her son Marc both online and in the studio, and he sent me some videos of Maryann, with the goal of getting her more comfortable and powerful on her bike so she can easily make the cutoff this year. When I saw her video, two things were immediately apparent. She was very fit and flexible, but had a terrible bike setup. To my eyes, it was her fit that was holding her back – nothing else.

Maryann has a road bike and a new tri bike was not in the cards this year, so we would make do. I felt it would be possible to improve both her comfort and power while keeping her reasonably aero. Even though she will be riding at mid-teens speeds, I felt there was no reason to have her set up like a door going down the road – there are plenty of spots on the Placid course where aerodynamics would help her achieve her goal. But my first task would be to get her comfortable and able to put full power to the pedals. I could clearly see that her saddle was very low, her seat angle too slack, and her hip angle too tight, so plenty to improve upon.

After a few back-and-forths with Marc, a switch to an Adamo Typhoon saddle, new stem, and much tweaking, we got her into a much better position:

Maryann has been riding her new setup for a while, and here is some really great (unprompted) feedback I just received from her:

“Up to this point all your communications about me and my bike fit have been with my son Marc. Well I’ve been riding more and more since the final adjustments and just have to let you know how comfortable I am. It’s not only comfort. I just feel stronger, that’s the only way to express it to you. I’ve said to Marc that now all I have to do is put in the time to make it pay off. So thank you so much. I’ll be doing Eagleman 6/12; Tupper Lake 6/25; and then Lake Placid 7/24. I’m 69, but as you know will be racing 70-74 – so time will tell. I just wanted to let you know personally, how very much I appreciated your expertise in my behalf.”

After receiving that email, it has to be a great day, even if it is cloudy foggy and damp for the 30th day in a row here in New England! We will be in Placid cheering her on, and I think she has a great shot at doing it this year. Thanks Maryann!

Smaller riders can be difficult to fit properly into a good aero position, yet we have achieved good fit results with quite a few riders of smaller stature – those shorter than 5’4″, and especially athletes 5’2″ and under. Aerodynamics are actually quite important for smaller riders, since their absolute power output is relatively small. Hence on a flat road, their lower power means they have a tougher time fighting wind resistance. Sure, they have a smaller frontal area than a big rider (and hence less drag), but the decrease in frontal area is typically not nearly as large as the power decrease. They also tend to be lighter than big riders, and hence their weight doesn’t help them as much when descending. But a decent aero position can go a long way in overcoming these handicaps, so that the smaller rider can get to the bottom of the climb with the big guys – and then really shine with their excellent power/weight ratio.

Smaller riders are frequently sold bikes that are too large for them. Now, too large can take on many forms – but commonly the stack height of the bike it too tall for the rider, making it impossible to achieve an aggressive position. Certainly the reach can be too long as well, but it seems that many of the small frame designs, especially “women’s” bikes, are built way too high in front. This occurs in both road and tri frames. If you use a saddle height of say 60cm, which I see commonly in women of 5’2″ or smaller, you need a low stack frame if you have any designs on getting into an aggressive aero position.

Most of the bigger name tri frames have stack height of around 46-47cm in their smallest sizes. This will limit the amount of drop the a small rider can easily achieve. If we take the 60cm saddle height mentioned above, such a rider would only be able to get about 5-6cm of drop to their aerobar pads – and that assumes low-stack aerobars and a horizontal (-17 degree) stem. Since most bikes are sold with a smaller drop -10 to -6 stem and higher stack bars, this rider often finds that the max achievable drop is 0 to 3 cm. While this may be appropriate for some, it is rarely acceptable for a solid aero position.

It should go without saying here that if you are around 5′ 4″ or less and want to be aero, you should be considering bikes with 650c wheels. It is essentially impossible to build a bike with a stack below about 48 cm or so if it has 700c wheels. Many riders in the 5′ 4″ + range can also fit well on a low-stack 650c frame. In any case a smaller rider should be fit on a fitbike initially so that a particular bike design’s limitations do not restrict their positioning. Once the ideal fit coordinates are found, the fitter should be able to tell you what the max stack height is that will allow that position. Often times the same small rider with short legs has a relatively long torso, so they also need a relatively long reach frame.

The Kestrel Airfoil in 47cm is simply the lowest stack production frame available, and should be on any smaller rider’s list. It is literally the only production bike that will work well for certain athletes. At 43.7cm stack, it is a full 2.4cm+ (1″) lower in front than the 46+cm stack bikes that represent the lowest bikes made by most manufacturers. It also has a very low headset cap, so in effect if it typically 3cm or more lower than many other “smallest” bikes. It will give a 5′ rider the most flexibility in fit, bar choice, etc. Even the saddle height can get lower than most other bikes – down to about 55-56cm from center of BB. The 50cm Airfoil, which also has 650c wheels, provides the longest reach of any bike with a stack below 47cm. So once again, it can be the only good choice for a smaller rider with short legs.

We recently fit a 5′ rider on a 47cm airfoil that had been previously riding a 48cm Cervelo, with a 46cm stack and higher stack aerobars. She had the Cervelo seatpost all the way down and it was barely low enough. We outfitted the Airfoil with a flatter, longer stem than stock, and were able to position her at a steep effective seat angle of 81 degrees thanks to the Airfoil’s adjustable seat post. She went from looking like she should have a flower basket on her aerobars to looking like a pro.

A custom frame can occasionally be the only option for VERY small riders, but beware! I have worked with several custom frame owners and they unfortunately have generally been a disaster. Please make sure the fitter REALLY knows what he is doing, and that he has tri-specific experience. The worst cases often arise from fitters who only know road fit and try to spec a custom tri frame based on road fit parameters. A good example is shown below – this is another approximately 5′ athlete who was told that she MUST have a custom bike. Clearly that was wrong, and the custom fit was terrible. The right stock frame with the right bars worked just fine.

I should also mention that any small rider should be on 165mm (ideally smaller but good luck finding them) cranks. This will allow a higher saddle, less knee and hip compression at the top of the pedal stroke. If we look at an average rider, maybe 5′ 10″ with a 74cm saddle height on 172.5mm cranks, the crank length is 23% of their saddle height. For the rider with the 60cm saddle height on 165 cranks, the crank arm is over 27% of their saddle height, meaning their foot is proportionately higher at the top of the pedal stroke, which results in a tighter hip angle. This would be equivalent to the average rider using a 200 mm crank!! To be equal, the small rider really needs 140mm cranks. So it is also typically important to position a smaller rider with a very steep seat angle to help open the hip angle.

There are things that can be done to your existing bike even if it is higher than ideal in front. Get a level, or even a negative drop stem (25 or 30 degrees). Use low stack aerobars (Vision Tech, Zipp Vuka integrated, 3T Mistral, Oval A900, etc – but also be aware that the reach of each of these bars varies greatly). A good fitter should be able to calculate exactly what you need to achieve the desired fit.

The good news is small athletes CAN get just as good a fit as average ones. And in most cases, they don’t need a custom frame. They do need to obtain good fit coordinates from a fit bike session with a knowledgeable fitter, and then have the proper frame and/or components specified. In all cases this must take into account sufficient drop and reach, as well as hip angle so that the athlete can be aero, powerful, and comfortable.

We just received our first Adamo Time Trial saddles – ISM’s latest offering. So far I have ridden it twice on the trainer, and another teammate is also testing it out. I have been a long-time Adamo Race user, and although all Adamos are excellent, for me I haven’t found one I like better than the race and neither has Lis. The Race is well suited to an aggressive aero position where the rider rolls his pelvis forward and hence sits mostly on the pubic bone as opposed to the sit-bones.

The new TT saddle is VERY similar to the Race as you can see from the pics. The big difference is the nose profile, as seen from the side. The TT has a sloped, curved nose while the Race is square. Otherwise the saddles are essentially identical. You would think it might be hard to tell them apart on the bike, but they really do feel quite different. For me, the jury is still out. For you, you will like the TT if the corners of the Race’s nose cause chafing or irritation. Hence I think if you tend to sit far forward on your Adamo Race or Road and have an aggressive position, the TT may be the saddle for you.

The TT also appears to have bigger gel pads on the noses which make the noses look wider – but doesn’t make them feel that way. They do seem to change the feel of the nose some, and I felt that I had to tilt the saddle down a tiny bit more than my Race to prevent the “nosy” feeling.

Look for future reports on the TT if I ever get to ride outdoors again…

Yipes I have really been neglecting my blog. But fitting comes first, and another reason I have been too busy to type is the popularity of our Kestrel bikes. If I’m not fitting I am building! For 2011, the 4000 tri/tt bike is latest and greatest, but let’s not forget two of Kestrel’s stalwarts: the Airfoil and the Talon. For 2011 both bikes get Oval Concepts components including nice carbon clincher wheels with aluminum braking surfaces. These are 45mm deep, so race worthy or just very nice as training wheels.

The 2011 Airfoil sports a striking black/white/yellow scheme that has been receiving much praise around our shop. As always, the Airfoil remains a long/low shape best suited to short-legged long-torso riders, or else any rider that really lays out on the bike with lots of drop.

Also don’t forget that the 47cm airfoil is THE lowest-stack production tri frame. I recently was able to fit a young lady on one who was notably under 5 feet tall. If not for the Airfoil, she would’ve had to go custom.

The Oval A900 bars are very adjustable and very aero, but also work best in a low-stack configuration. So again, don’t expect a high front end with the Airfoil. The flat base bars seem very comfortable with good hand position options.

Another new twist for 2011 are the Oval A700 brakes. These are similar to some of the super-lightweight brakes out there in design. They utilize a roller cam to apply force to the calipers, which are skeletonized. So they appear quite light.

But since there is no way to ride outside around here in the winter wasteland, braking ability will have to be tested in the future. Maybe the very distant future at this rate. For 2011 there is only one version of the Airfoil as seen above, equipped with ultegra. Msrp is in the low $4′s.

The Talon has also been a foundation of Kestrel’s lineup for years, and has gone through a few frame updates. For 2011, the components are the main changes. As always, the Talon is available as a road or tri configuration – the difference being the front end components. So it either serves as a very nice aero road bike, or hybrid road/tri bike.

The adjustable seat post allows the saddle to be pushed forward a few cm, which will achieve a full 78+ degrees on small frames or more like 76 degs on bigger frames. So it can work well as a tri bike for those who need a high stack and prefer a slacker seat angle. As a road bike, the Talon is full-on race geometry – long and low. The new Rt-1000 will fill out the Kestrel road bike line with a shorter reach – higher stack geometry suited to less aggressive road positions. We expect these to be available in late March.

The Talon Tris get Profile front ends again this year. So this adds to the already high stack. The SL version gets ultegra and the nice Oval 745 carbon rims and Ultegra.

The road SL gets sharp-looking carbon Oval stem and bars.

All models get the same Oval A700 brakes as on the Airfoil. The SL’s paint job is quite striking – white and clear carbon with navy and gold trim. Once again, it is receiving rave reviews here at the Lab. The Sl’s list in the mid $3′s while the regular 105-equipped versions, which are red and black are in the low $2′s.

What of the 4000? The 2011 ultegra and Sram Red versions are starting to hit – all equipped with Oval wheels and components (although some may be receiving Profile CX-3 bars instead of the Oval A900′s). The Di2 equipped version seems to still be a ways off though. Stay tuned for further updates.

Finally got around to finishing my review of Kona Pro bikes – so let’s dive right in. (click on pics for full size images)

The Commerz Bank crew were very prominent with their new matching Scott Plasma 3′s done in in matte gray with yellow highlights. These are the same frames used by Pro Tour Team Columbia HTC in TT’s, and feature “sunken headsets” so that the trailing edge of the stem blends into the top tube. This works especially well with a level stem, but Mattias Hecht used an upright stem along with tall elbow risers. Hecht chose an Adamo like many pros this year, in this case a Podium. It also looks as if he opted for a Vittoria Pit Stop canister instead of carrying a tubular spare.

Normann Stadler’s Plasma was very similar, but sported very neatly coiled tubular spares under the saddle. Also note the aero rear derailleur jockey wheels, made by Berner. This looked to be the same setup used by Lance on his Trek TT bike.

Eneko LLanos’s BH sported Hed Jet 9 clinchers and an unusual stem cap water bottle mount. This is probably a Hed Lollipop, but the bottle seems mounted even higher than the stem cap. Perhaps this is a wind tunnel revelation: maybe the high water bottle helps direct flow away from the rider’s torso, or maybe it’s just more comfortable. Completing the Hed suite are the Corsair aerobars.

Timo Bracht was the renegade of the Commerzbank team, opting to ride a Giant Trinity. Timo used Q-rings, Di2, and like Hecht relied on a Pit Stop instead of a spare.

TJ Tollakson is by now well known for his one of a kind aerobar setup and mantis position. TJ has incorporated athletic supporter cups and shin pads to support his elbows and forearms in a nearly vertical position. He also has two water bottles mounted between the aerobars, for a grand total of 5 bottle cages. My guess is one or both of the aerobar bottles are decoys used for aerodynamic purposes. TJ has spent time tweaking this setup in the tunnel, and he must have found something worthwhile to bother with all this stuff dangling from his bars.

Aero-wise, once you have your frontal area minimized, the only thing left to exploit is shape. Remember that two objects with the same frontal area can have very different drag coefficients. An empty ice cream cone will have much less drag pointy end first vs. flipping it around open end first, even though the frontal area is the same. Downhill ski racers keep their hands up in front of their faces to make themselves more streamlined. TJ is trying to achieve the same thing with his high hands and bottlles filling in the gaps between his arms. It still looks super uncomfortable… Also note his helmet – no aero tail and in fact it doesn’t look like a road helmet at all. This could be an attempt to minimize drag via frontal area reduction. MIT studied aero helmets in the wind tunnel, and found that a bare head was actually more aero due to the greatly reduced frontal area – most aero helmets are much bigger than your head. So there is a case where reduced frontal area beats the more aero shape attached to a greater frontal area.
